HO Locomotives <<-- Previous   index   Next -->> P2k SW1200 sound 9 This shows the decoder in place in the cab, though the main thing visible here is the 50 Ohm resistor that is fitted in series with the speaker for protection (as recommended by TTX). The decoder and all other visible components and wiring in the cab are painted matt black to minimise their visibility. It would probably be possible to fit the glazing into the side windows, but I had another plan. 13(23) Copyright Mike Sheridan, 2003-2006 Created with Web Picture Creator 1.50
